new BS-1200 Shoulder Ballast Cleaning railway locomotive

CRRC Taiyuan developed and manufactured BS-1200 (SBC - HP3) Shoulder Ballast Cleaning locomotive —heavy-duty railway maintenance equipment with high efficient through technology import from Loram Maintennace of Way,Inc.in the United States. This machine is used for ballast cleaning operation on shoulders of the track. The total length is 45 meters, and the maximum productivity is 1200 m³/h. It can complete automatically the whole process of ballast excavating, ballast conveying, screening, distributing and regulating. Through reducing the ballast contamination rate of ballast of the track shoulder, it can enhance drainage capacity of the ballast bed and decrease the problems, such as ballast bed hardening, mud-pumping and so on, and prolong the overhaul period of the railway. This machine,which has high work efficiency, multiple function, a high degree of integration, reasonable structure, as well as reliable performance, represents the highest level of the similar products in the world.


The Main Technical Parameters:

Max.self-propelled speed:80km/h

Max.allowable coupling speed:20km/h

Operation speed:  variable from 0~4km/h

Min.negotiable curve radius during travelling: 180m

Max.capacity of digging and screening: not less than 1200m³/h

Max.digging depth≥850mm(under railway surface)

Screening efficiency: The cleaned ballast returned to the shoulders shall not exceed 3% fines when operating at the rated capacity of 1200m³/h with initial ballast bed contamination less than 30% fines. And the usable ballast contained in the waste shall not exceed 5% in weight.

Ballast Regulation: The machine is able to regulate the reclaimed clean ballast. The maximum operation width on each side of the track shall be not less than 3.0m (from centerline of track)
