DF10D diesel locomotive

DF10D diesel locomotive

DF10D diesel locomotive

Product Details:

Place of Origin: China
Brand Name: CRRC
Certification: AAR, GOST,IRIS, TSI, OEM
Model Number: 08

Payment & Shipping Terms:

Minimum Order Quantity: 10
Delivery Time: 3 months
Payment Terms: L/C OR T/T
Supply Ability: 500 SET/ YEARS
Contact Now
Detailed Product Description



 Taiyuan Railway transportation Equipment  Co., Ltd. is a main factory for making and overhauling of diesel locomotive and  electric locomotive, which can manufacture 10000 sets and repair 5000 sets. and our main advantagment   is Railway freight wagon , products include the design and manufacture of gondola wagon, ballast hopper wagon, coal hopper wagon , flat wagon, tank trucks, automatic dumping cars etc.

DF10D diesel locomotive

Product class: diesel locomotive

Introduction: DF10D diesel locomotive, a product of DF10 series locomotive, is heavy-duty shunting and transfer diesel locomotive manufactured by CRRC Taiyuan Railway Co., Ltd. Maximum service power of diesel engine: 2200 kW; maximum speed: 100 km/h; length: 18,800mm; axle arrangement: Co-Co; transmission mode: AC-DC transmission.

Technical parameters:

Purpose: heavy-duty shunting and transfer

Transmission mode: AC-DC transmission

Gauge: 1,435mm

Axle arrangement: Co-Co

Axle load: 23±3%t

Wheel base of bogie: 2×1,800mm

Minimum radius of curvature negotiable: 100m

Maximum service speed: 100km/h

Continuous speed: 17.8km/h

Starting tractive effort: 480.9kN

Continuous tractive effort: 341.7kN

Diesel model: 12V240ZJD

Maximum service power of diesel engine: 2,200kW

Outline dimensions: 18,800×3,305×4,713mm
