KZ70H high quality Ballast Hopper Wagon from CRRC Taiyuan

KZ70H high quality Ballast Hopper Wagon from CRRC Taiyuan

    • KZ70H  high quality Ballast Hopper Wagon from CRRC Taiyuan
    • KZ70H  high quality Ballast Hopper Wagon from CRRC Taiyuan
    • KZ70H  high quality Ballast Hopper Wagon from CRRC Taiyuan
    • KZ70H  high quality Ballast Hopper Wagon from CRRC Taiyuan
    • KZ70H  high quality Ballast Hopper Wagon from CRRC Taiyuan
  • KZ70H  high quality Ballast Hopper Wagon from CRRC Taiyuan

    Product Details:

    Place of Origin: Shanxi China
    Brand Name: CRRC
    Certification: AAR, GOST,IRIS, TSI, OEM

    Payment & Shipping Terms:

    Minimum Order Quantity: 10
    Price: 45000-60000
    Delivery Time: 3 months
    Payment Terms: L/C OR T/T
    Supply Ability: 10000 SET/ YEARS
    Contact Now
    Detailed Product Description

    This ballast hopper wagon from CRRC Taiyuan utilized for new-and-old line ballasting service and other bulk goods transportation is suitable for operating on China standard gauge railway. It is mainly comprised of car body, bottom door, top and bottom drive mechanisms, air control pipeline device, bogie, brake equipments, coupler and draft gear, etc. Unloading outlets installed on the both side and center of car bottom can be operated by pneumatic control or manual control. The car body and bottom door are of all steel welded structure, and the car adopts ZK5 bogie or ZK6 bogie, air brake system with120 type control valve, NSW type hand brake, 17 type coupler and MT-2 type draft gear....

    Main technical parameters:

    Loading capacity(t)

    70

    Tare weight(t)

    ≤23.8

    Volume(m3)

    42

    Quantity of unloading outlet:

    Two are on the both sides, and two are on the center

    Operating speed (km/h)

    120

    Min. radius of curvature negotiable (m)

    145
